Page 2

IMAGE SENSOR
1/3” 1.3 MegaPixel CMOS Sensor
TOTAl NuMBER OF PIXElS
Approx. 1.3 Million Pixels
SCANNING METHOD
Progressive Scan
ZOOM
3x Optical Zoom
FOCAl lENGTH / F-STOP
F= 2.8 (W) – 8.4 mm (T) / F1.2 - 2.0
ANGlE OF VIEW
101.2° (W) / 33.7° (T)
ROTATION RANGE
350° ( ± 175°)
PAN ANGlE RANGE
350° ( ± 175°)
TIlT ANGlE RANGE
150° ( ± 75°)
MOVING RATE
Pan: 19.2°/Sec, Tilt: 14.2°/Sec, Rotate: 43.7°/Sec
DAY/ NIGHT MODE
Auto / Manual
IR CuT FIlTER
Yes
MINIMuM IlluMINATION
COlOR 0.018*
B & W
0.001*
FOCuS
One-shot AF / Manual / Fixed at Infinity
FOCuS RANGE
Day Mode: 1 Ft. / Night Mode: 3.3 Ft.
AuTO EXPOSuRE
Auto / Flickerless / Shutter Priority AE / Manual
SHuTTER SPEED
1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500,
1/1000, 1/2000, 1/4000, 1/8000 sec.
Auto / Select light Source (Warm Fluorescent, White Fluorescent,
WHITE BAlANCE
Daylight Fluorescent, Mercury lamp, Sodium lamp,
Halogen lamp) / lock (One-shot WB) / Manual
METERING MODE
Center-Weighted / Average / Spot
EXPOSuRE COMPENSATION
7 levels
SMART SHADE CONTROl
7 levels
VIDEO COMPRESSION METHOD
H.264 / MJPEG
OuTPuT IMAGE/VIDEO SIZE
H.264
1280 x 960, 640 x 480, 320 x 240
MJPEG
1280 x 960, 640 x 480, 320 x 240, 160 x 120
VIDEO QuAlITY
MJPEG / H.264: 5 levels
FRAME RATE
H.264: 10 / 15 / 30 fps / MJPEG: 0.1 - 30 fps
MAXIMuM FRAME RATE
H.264: 30 fps @ 1280 x 960 / MJPEG: 30 fps @ 1280 x 960
SIMulTANEOuS ClIENT ACCESS
H.264: 10 clients / JPEG: 30 Clients
AuDIO COMPRESSION METHOD
G.711 μ-lAW (64kbps)
AuDIO COMMuNICATION
2-Way Full Duplex
AuDIO PlAYBACK
Audio files can be played on event detection
TCP/IP, uDP, HTTP, FTP, SNMP (MIB2), SMTP (client), DHCP
Pv4
(client), DNS (client), ARP, ICMP, POP3, NTP, SMTP authentication,
PROTOCOl
WV-HTTP (Canon protocol), ONVIF
IPv6
TCP/IP, uDP, HTTP, FTP, SMTP (client), DNS (client), ICMPv6, POP3,
NTP, SMTP authentication, WV-HTTP (Canon protocol), ONVIF
COMMuNICATION ENCRYPTION
HTTPS, IPsec
CAMERA CONTROl uSER TYPES
Administrator / Authorized users / Guests
VIEW RESTRICTION
Available
PRIVACY MASK
up to 8 locations
CONNECTION RESTRICTION
username / password, IP address restriction
VIDEO ANAlYTICS (Intelligent Function)
Image: Moving Object Detection / Removed Object Detection /
Abandoned Object Detection / Camera Tampering Detection
Field of Detection: Max. 15 places
Sound: Volume Detection
IMAGE uPlOAD
JPEG: FTP / HTTP / SMTP
TEMPORARY STORAGE
Removable SD / SDHC card (up to 32gb), up to 1fps
EVENT NOTIFICATION
HTTP / SMTP (e-mail)
NETWORK
1 RJ-45 (100Base-TX, Negotiation: auto / full / half, IEEE 802.3af
AuDIO TERMINAlS
INPuT
1 Mini-Jack Connector (Mono), lINE IN / MIC IN
OuTPuT
1 Mini-Jack Connector (Mono), lINE OuT
EXTERNAl DEVICE I / O TERMINAl
Input: x 2, Output: x 2
TEMPERATuRE / HuMIDITY
14°~122° F / -10°~50° C / 5~85%RH (No Condensing)
-22°~122° F / -30°~50° C / 5~85%RH (w/ opt. Heater)
POWER OVER ETHERNET
via lAN Connector (IEEE802.3af compliant)
OPTIONAl AC ADAPTER
AC 100V-240V (PA-V17)
OPTIONAl EXTERNAl POWER
AC 24V / DC 12V
WITH POWER OVER ETHERNET
Approx. 8.6 Watts
WITH OPTIONAl AC ADAPTER
Approx. 10.9 Watts
DC INPuT (DC 12V)
Approx. 9 Watts
AC INPuT (AC 24V)
Approx. 8.3 Watts
WITH OPTIONAl HEATER uNIT (24V AC needed) Approx. 18.9 Watts
DIMENSIONS
7.09 x 5.79 in. (180 x 147 mm)
WEIGHT
4.22 lbs (1910 g)
INGRESS RESISTANCE RATING
IP66
BuNDlED SOFTWARE
VB Initial Setting Tool, RM-lite
CAMERA UNIT
CAMERA SERVER
INTERFACE
OPERATING
TEMPERATURE
POWER SUPPLY
POWER
CONSUMPTION
ENCLOSURE
POWER SUPPLY
PRODuCT NAME:
VB-M600VE
ITEM CODE:
4960B001
uPC CODE:
13803131529
VB-m600Ve
SPECIFICATIONS
OPTIONAL ACCESSORIES
ITEM CODE NO.
DESCRIPTION
2245B001
PA-V17 AC Adapter
5004B001
PS600-VB Junction Box Mounting Kit
5091B001
SR600-VB Recess Mounting Kit
5092B001
Hu600-VB Heater unit (needs 24V AC)
OPTIONAL SOFTWARE
ITEM CODE NO.
DESCRIPTION
4973B001
RM-lite-V (Aiddtional Installation license)
P R O F E S S I O N A l P R O D u C T S
For more info:
Call 1-800-OK-CANON (1-800-652-2666)
www.usa.canon.com/professional
0154W942
Impact Resistance
The VB-M600VE contains a new damping
mechanism that allows the lens to move
15mm inside the camera body. This, with
a vandal resistant enclosure, allows for
the camera to absorb impacts.
Water Resistant
The VB-M600VE is both dust and water
resistant with an Ingress Resistant
Rating of IP66, which can keep out
heavy sprays of water at any angle.
Cold Weather Resistant
The VB-M600VE can be purchased with an optional heater that allows for
camera operation down to -22° F (needs AC 24V).
impact and weather Resistance
*Ratings based on F1.2, 1/8 second and Smart Shade Control on.
©2011 Canon U.S.A., INC. All rights reserved. Specifications and availability are subject to change
without notice.Weight and dimensions are approximate. All images and effects are simulated.
Canon and DIGIC are registered trademarks of Canon Inc. in the United States and may also be
registered trademarks in other countries. IMAGEANYWARE is a trademark of Canon. “ONVIF” and
are trademarks of ONVIF Inc. Other names and products not mentioned above may
be registered trademarks or trademarks of their respective companies. Warning: Unauthorized
recording of copyrighted materials may infringe on the rights of copyright owners and be contrary
to copyright laws.
onViF Conformant Product
The VB-M600VE is compatible with the ONVIF (Open Network Video
Interface Forum) version 1.02 protocol, a standard communication
protocol. It is now easier to integrate the VB-M600VE with other ONVIF
compliant 3rd party products. The VB-M600VE is also backwards
compatible with earlier versions of the ONVIF protocol.
