23 103509
OWNER’S MANUAL
PARTS LIST
RFP28TC
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 21 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 098304-01 Screw, #10 x 3/8" 6
2 100566-01CK Front Panel 1
3 100573-01BR Screen Assembly 1
4 100568-01BR Burner Shield 1
5 100903-04 Log 1
6 M11084-38 Screw, #8 x 3/8" 2
7 099066-01 Mounting Bracket 1
8 M11084-26 Screw, #10 x 3/8" 8
9 100571-01BR Deflector Unit 1
10 098271-03 Ignitor Cable 1
11 098249-01 Nut, M5 2
12 099440-06 ODS/Pilot Assembly 1
12-1 098514-01 Thermocouple 1
12-2 098594-01 Ignitor Electrode 1
13 099126-02 Burner 1
14 098517-01 3/16" Pilot Tubing 1
15 098251-03 Injector 1
16 098250-01 Injector Holder 1
17 099415-06 Pressure Regulator 1
18 099553-01 Pilot Shield 1
19 103255-01 3/8" Outlet (Burner) Tubing 1
20 103256-01 3/8" Inlet Tubing 1
21 103837-03 Bracket Support 1
22 098275-01 3/8" NPT Plug 1
23 098522-13 Thermostat Gas Valve 1
24 105556-01 Cabinet 1
25 097159-04 Piezo Ignitor 1
26 098304-03 Screw, #8 x 3/8" 5
27 101046-01 Log Strap 2
PARTS AVAILABLE — NOT SHOWN
100562-01 Lighting Instructions Plate 1
100563-01 Warning Plate 1
101899-01 Brass Trim Assembly 1
100642-01 Hardware Package 1
100769-02 Brass Trim Hardware 1
100565-01 Warning Plate Fastener Kit 1
101416-29 Instructional Video 1
