VIEWING IMAGES ON A COMPUTER
114
6. Connect the bundled AC adaptor to the [DC IN
5.3V] connector of the USB cradle, and then
plug it in to a household power outlet.
• Note that the shape of the AC adaptor depends on
the area where you purchased the camera.
7. Connect the USB cable that comes bundled
with the camera to the USB cradle and your
computer’s USB port.
• Take care when connecting the USB cable to the
USB cradle or your computer. USB ports and cable
plugs are shaped for proper positioning.
• Plug the USB cable plugs into the ports securely, as
far as they will go. Proper operation is not possible if
connections are not correct.
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
USB port
Connector A
USB cable
(bundled)
[USB]
Connector B
