2. I
NTRODUCTION
Features
CONTROL FEATURES
•
5 or 13-channel DMX-512 LED moving yoke
•
Pan: 540 o / tilt: 270 o
•
RGB color mixing
•
Gobo wheel
9 gobos + open
Gobo wheel spin effect
•
Variable electronic strobe
•
Variable electronic dimmer (0 – 100%)
•
Vector speed channel for pan/tilt, RGB color mixing and color macros
•
Built-in movement macros via master/slave or DMX
ADDITIONAL FEATURES
•
User-selectable basic or advanced operating modes
•
User-selectable pan/tilt ranges
Pan: 540
°, 360°, 180°
Tilt: 270
°, 180°, 90°
•
Compact and lightweight
•
LED display menu with invert
•
Reset to factory settings option
•
Display auto on/off
•
Pan/tilt invert option
•
Fan cooled
OPTIONAL CONTROLLERS
•
Easy Controller (CA-9)
DMX Channel Summary - 13 Channel Mode
C HANNEL F UNCTION
1 Pan
2 Pan Fine
3 Tilt
4 Tilt Fine
5 Vector Speed (Pan/Tilt)
6 Dimmer/Strobe
7 Red
8 Green
9 Blue
10 Color Macros
11 Vector Speed (Color)
12 Movement Macros
13 Gobo
MiN™ Spot User Manual 5 2008-07-15/12:39
