DMX Channel Values (5 Channel)
C HANNEL V ALUE F UNCTION
1 000 Ù 255 Pan
2 000 Ù 255
Tilt
3
000 Щ 007
008 Щ 134
135 Щ 239
240 Щ 255
Dimmer/Strobe
Closed
100-0%
Strobe (slow → Fast)
Open
4
000 Щ 007
008 Щ 021
022 Щ 035
036 Щ 049
050 Щ 063
064 Щ 077
078 Щ 091
092 Щ 105
106 Щ 119
120 Щ 133
134 Щ 147
148 Щ 161
162 Щ 175
176 Щ 189
190 Щ 203
204 Щ 217
218 Щ 231
232 Щ 244
245 Щ 255 Color Macros
No Function
White
Red
Green
Blue
Cyan
Magenta
Yellow
Purple
Orange
Chartreuse
Pink
Brown
Gold
Crimson
Violet
Crepe
Color-Change Macro 1
Color-Change Macro 2
5
128-255
Gobo
0~12
65~77
13~25
78~90
26~38
91~103
39~51
104~116
52~64
117~127
Scrolling Gobo Effect slow → fast
