DMX Channel Values (13 Channel)
C HANNEL V ALUE F UNCTION
1
000 Ù 255
Pan
2 000 Ù 255
Pan Fine
3
000 Ù 255
Tilt
4 000 Ù 255
Tilt Fine
5 000 Ù 255 Vector Speed: (Normal → Slow)
6
000 Щ 007
008 Щ 134
135 Щ 239
240 Щ 255
Dimmer/Strobe
Closed
100-0%
Strobe (slow → fast)
Open
7
000 Ù 255 Red
0-100%
8
000 Ù 255 Green
0-100%
9
000 Ù 255 Blue
0-100%
10
000 Щ 007
008 Щ 021
022 Щ 035
036 Щ 049
050 Щ 063
064 Щ 077
078 Щ 091
092 Щ 105
106 Щ 119
120 Щ 133
134 Щ 147
148 Щ 161
162 Щ 175
176 Щ 189
190 Щ 203
204 Щ 217
218 Щ 231
232 Щ 244
245 Щ 255 Color Macros
No Function
White
Red
Green
Blue
Cyan
Magenta
Yellow
Purple
Orange
Chartreuse
Pink
Brown
Gold
Crimson
Violet
Crepe
Color-Change Macro 1
Color-Change Macro 2
11 000 Ù 255 Vector Speed (Color)
12
000 Щ 007
008 Щ 023
024 Щ 039
040 Щ 055
056 Щ 071
072 Щ 087
088 Щ 104
105 Щ 117
118 Щ 135
136 Щ 151
152 Щ 167
168 Щ 183
184 Щ 199
200 Щ 215
216 Щ 231
232 Щ 247
248 Щ 255 Movement Macros
No Function
Auto Program 1
Auto Program 2
Auto Program 3
Auto Program 4
Auto Program 5
Auto Program 6
Auto Program 7
Auto Program 8
Sound Active1
Sound Active 2
Sound Active 3
Sound Active 4
Sound Active 5
Sound Active 6
Sound Active 7
Sound Active 8
13
128-255
Gobo
0~12
65~77
13~25
78~90
26~38
91~103
39~51
104~116
52~64
117~127
Scrolling Gobo Effect slow → fast
MiN™ Spot User Manual 14 2008-07-15/12:39
