Stand-Alone Mode (Auto Mode):
This mode allows a single unit to run to a factory installed program in one of two speeds.
1) To set the fixture in auto mode Fast, select . Once confirmed the display reads
2) To set the fixture in auto mode Slow, select Once confirmed the display reads
Master/Slave Mode (Master Sound):
This mode will allow you to link up to 32 units together without a controller.
1) Use standard DMX cables to daisy chain your units together via the DMX connector on the rear
of the units. Proper performance it may be necessary to use a terminator at the last fixture. For
more information about terminators, see page 8.
2) Choose a unit to function as the Master. Select NAFA/NASL or NStS (see below for readout)
depending upon which master mode you require. The master unit must be the first unit in line.
Finally, chain the units together using DMX cable.
Master Auto or
Master Sound
becomes when confirmed
3) Select slave function by using the Up/Down keys to reach SLAv in the Master/Auto menu on the
slave units, and they will react in the same as the Master.
Slave
becomes when confirmed
Easy Controller Mode
:
This mode allows users to control the MiN Spot with the easy controller.
1) To place the unit in easy controller mode, select
2) In Easy controller mode, the fixture will react as follows:
4)
DMX Mode
B UTTON D ESCRIPTION
Stand By Blacks out the unit.
Function First click: strobe on. Second click: strobe off.
Mode
First click: sound-active mode (LED will be on). Second click: auto mode (LED will be
off).
This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page #17.
1) The default mode for the fixture is DMX, which appears as on the LED Readout.
MiN™ Spot User Manual 13 2008-07-15/12:39
