background image

42

APPENDIX

SERVICE

WARNING: High voltages are used to operate this projector. Do not attempt to open cabinet.

You can often correct operating problems yourself. If a projector fails to work properly, see "TROU-
BLESHOOTING" section on page 48, 49. To correct failure, try "Solutions".

If after following all operating instructions, you find that service is necessary, contact Christie Service Station
or store where you purchased unit.
Give model number and explain difficulty. We will advise you how to obtain service.

This symbol on the nameplate means the product is Listed by Underwriters
Laboratories Inc. It is designed and manufactured to meet rigid U.L. safety
standards against risk of fire, casualty and electrical hazards.

The CE Mark is a Directive conformity mark of the European Community (EC).

AC Power Cord
VGA Cable
2 Types Light-Block Sheet (For option lens)
Lens Mounting Adapter

Accessories

TECHNICAL SPECIFICATIONS

1.21" TFT Active Matrix type, 3 panels

Multi-media Projector

46.3 lbs (21 kg)

17.3" x 9.1" x 23.8" (439 mm x 230 mm x 605.6 mm)

1366 x 768 dots

3,147,264 (1366 x 768 x 3 panels)

PAL, SECAM, NTSC, NTSC4.43, PAL-M and PAL-N

Up and Down

800 TV lines

INT. SP. Stereo (R and L), 3 watt RMS (T.H.D. 10%)

41 ˚F ~ 95 ˚F (5 ˚C ~ 35 ˚C)

14 ˚F ~ 140 ˚F (-10 ˚C ~ 60 ˚C)

Projector Type

Net Weight

Dimensions

(W x H x D)

Panel Resolution

Number of Pixels

Color System

Scanning Frequency

Horizontal Resolution

Built-in Speakers

Operating Temperature

Storage Temperature

LCD Panel System

265 watt type x 2

Projection Lamp

0˚ to 6.9˚

Feet Adjustment

480i, 480p, 575i, 575p, 720p, 1035i, 1080i-50 and 1080i-60

High Definition TV Signal

AC 100 ~ 120 V (8.0 A Max. Ampere), 50 / 60 Hz (The U.S.A and Canada)
AC 200 ~ 240 V (4.0 A Max. Ampere), 50 / 60 Hz (Continental Europe)

Voltage and
Power Consumption

H-sync. 15 ~ 120 KHz, V-sync. 50 ~ 120 Hz

Motorized Lens Shift

HDB 15-pin Terminal (Analog), RCA Type (Audio R and L)
and DIN 8-pin (Control port)

Input 1 Jacks

Serial port in (DB 9), Serial port out (DB 9), USB port and
Audio Monitor out (RCA Type R and L)

Other Jacks

● Specifications are subject to change without notice.

● LCD panels are manufactured to the highest possible standards. At least 99.99% of the pixels are effective,

however a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD
panels.
