Rev -, 5/10 Page 6 of 6
9. Assemble bottom crossbar onto bottom backstay pipes using pipe clamps. Since this rear crossbar is the
same length as the football goal crossbar, the pipe clamps should be in the same orientation for both.
10. Insert plastic pipe caps into bottom backstay pipes. This will help prevent water intrusion into frame.
Bottom left side crossbar Bottom right side crossbar
Bottom crossbar fully assemble
Install Training net: (Net sold separately)
1. Locate the upper corner of the net. Cut the 3/4" wide white one wrap x 4 yard into 9” lengths. Then
warp the 9” lengths of Velcro net tie along the crossbar. Secure the front edge of the net to the pipe
using 9” lengths of Velcro net tie.
