JAYPRO SPORTS
PORTABLE PRACTICE FOOTBALL / SOCCER COMBO GOAL
IMPORTANT NOTICE:
1) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING HARDWARE AND
STRUCTURAL INTEGRITY. REPLACE DAMAGED OR MISSING HARDWARE
IMMEDIATELY.
2) NEVER ALLOW ANYONE TO CLIMB OR HANG ON THE NET OR GOAL FRAME. AS
SERIOUS INJURY OR DAMAGE TO THE EQUIPMENT MAY OCCUR.
3) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE HAZARDOUS.
4) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS AND
RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR DEALER OR
JAYPRO SPORTS.
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED:
1) Socket set for 3/4” & 15/16” Hex Bolts and/or Crescent Wrench
1) Electric Drill with 1/4” Socket Bit or Driver
1) Hammer or Rubber Mallet
1) Stepladder or Staging (Scaffold)
1) 25’ (Minimum) Tape Measure
• Unpack all parts and check against parts list to ensure that all have been included.
• Identify all frame components and lay them out on a flat dry surface.
• Inspect all parts for damage. Report any damages to the trucking company.
ITEM DESCRIPTION PPG-4HS PPG-4C
1 238” LONG UPRIGHTS 2 2
2 23’-4” CROSSBARS (HIGH SCHOOL FOOTBALL GOAL) 2 N/A
3 18’-6” CROSSBARS (COLLEGE SCHOOL FOOTBALL GOAL) N/A 2
4 BOTTOM BACKSTAYS (GROUND) 2 2
5 BACKSTAYS (SUPPORT BRACES) 2 2
6 WHEEL FRAME CORNER WELDMENT 2 2
7 1.90” PIPE CLAMP “T” FITTING 16 16
8 1/2”-13 STOVER LOCK NUT, ZP 24 24
9 1/2” FLAT WASHERS, ZP 24 24
10 1/2”-13 x 3” HEX HEAD BOLT, ZP 24 24
11 ALUMINUM END CAP 2 2
12 PLASTIC END PLUG 2 2
13 10” WHEEL 4 4
14 5/8” FLAT WASHER, ZP 4 4
15 5/8”-11 LOCK NUT, ZP 2 2
16 5/8”-11 x 10” HEX HEAD BOLT, ZP 2 2
17 7/8” O.D. x 5/8” I.D. x 1” BRONZE BUSHING 4 4
18 #8 x 3/4” HEX HEAD FLANGE SELF-DRILL SCREW, ZP 4 4
19 TRAINING NET (OPTIONAL IF PURCHASE) 1 1
20 WIND STREAMERS (OPTIONAL IF PURCHASE) 2 2
21 3/4" WIDE WHITE ONE WRAP x 4 YD (IF PURCHASE) 1 1
22 MOVEABLE TARGET (IF PURCHASE PPG-3TG OR PPG-2UTG) PER ORDER PER ORDER
QTY: EACH UNIT
