GBA Series Breakaway Basketball Goal Instructions
- 8 of 9-
JSL-Inst045
www.jayprosports.com
6 Breakaway Force Adjustment
IMPORTANT: Only adjust the horizontal spring.
1. Remove cover plate as shown in Figure 5-1.
2. Insert the supplied pin into the hole in the spring adjust mechanism.
Use the supplied wrench to adjust the spring tension nut as shown in
Figure 6-1.
Figure 6-1: Adjust spring tension.
3. Reinstall cover plate.
Decrease Force
Increase Force
