SKU 99637 For technical questions, please call 1-800-444-3353. Page 15
PARTS LIST
Part # Description Part # Description
1 Exhaust Cap 38 O-Ring
2 Hex Bolt 39 Trigger
3 Spring Washer 40 Pin
4 Cylinder Cap Unit 41 Hex Bolt
5 Seal 42 Spring Washer
6 Internal Lining 43 Guide (Work Contact Element)
7 O-Ring 44 Pin
8 Compression Spring 45 Spring
9 Gasket (Cylinder Cap) 46 Hex Bolt
10 O-Ring 47 Drive Depth Adjuster
11 Head Valve/Piston Valve 48 Nut
12 O-Ring 49 Spring
13 O-Ring 50 Ring
14 O-Ring 51 Safety
15 Collar 52 E-Ring
16 O-Ring 53 Stop Ring (Depth Control)
17 Piston Up Cover & Driver 54 Hand Grip
18 O-Ring 55 O-Ring
19 Lining Ring 56 End Cap
20 Cylinder 57 Air Plug
21 O-Ring 58 Hex Bolt
22 O-Ring 59 Tail Hanger
23 Bumper 60 Nut
24 Air Plug 61 Hex Bolt
25 Body 62 Spring
26 Nozzle 63 Magazine Latch
27 Air Hose 64 Pin
28 Seal 65 Tail Cover
29 Trigger Valve Head 66 Hex Bolt
30 Spring 67 Magazine (A)
31 O-Ring 68 Fixed Block
32 Trigger Plunger 69 Bar
33 O-Ring 70 Spring
34 Valve Body (Lower) 71 Pin
35 Spring 72 Pusher
36 Trigger Plate 73 Magazine (B)
37 Pin 74 Set Plate
