Dc-input power entry module leds – Cisco 12406 User Manual
Page 19
4-19
Cisco 12006 and Cisco 12406 Router Installation and Configuration Guide
OL-11497-03
Chapter 4 Troubleshooting the Installation
Problem Solving with Subsystems
DC-Input Power Entry Module LEDs
shows the location of the LEDs on the DC-input PEM.
Figure 4-2
DC-Input Power Entry Module LEDs
summarizes the function of these indicators.
1
DC-input PEM
4
Captive screws on release levers
2
Handle
5
Air inlet for cooling fan
3
ON/OFF switch
–
–
Table 4-7
DC-Input PEM LED Indicators
LED Label
Color
Function
OUTPUT OK
Green
PEM is operating normally in a powered-on condition.
INPUT OK
Green
DC power is present at the PEM input and within the specified limits.
MISWIRE
Amber
Indicates input is wired backward at the PDU input.
