Basic Operations
English
9
CX609
3-1. Each time you press the [
w] or [z] button,
the tone effect changes in the following
order:
“CUSTOM”
↔ “EXCITE” ↔ “IMPACT” ↔
“B-BOOST”
↔ “OFF”
CUSTOM : user custom
EXCITE : bass and treble emphasized
mid emphasized
IMPACT : bass and treble emphasized
B-BOOST : bass emphasized
OFF : no sound effect
When “CUSTOM” is set:
3-1. Press the [ ] button.
3-2. Press the [
x] or [v] button to select the
“BASS, MID” or “TREBLE” mode to adjust.
3-3. If you want to set the flat, press the [ ]
button to return to the “CUSTOM” mode,
then press and hold the [
] button
(1sec.), bass/mid/treble characteristics
become flat and switch to the “CUSTOM”
mode.
When “EXCITE/IMPACT/B-BOOST” is set:
3-1. Press the [ ] button.
3-2. Press the [
w] or [z] button to adjust the
setting in the range of – 3 to +3.
∗ The factory default setting is “0”.
3-3. Press the [ ] button to return to the
previous mode.
● Adjusting the BASS/MID/TREBLE
This adjustment can be performed only when
the BEAT EQ is set to “CUSTOM”.
Note:
• While connected with the external amplifers,
please do not set the “BASS/MID/TREBLE” in
the maximum level. Otherwise the speakers may
be damaged.
3-1. Press the [ ] button.
3-2. Press the [
x] or [v] button to select as
following order.
“BASS” ↔ “BASS” ↔
“BASS” ↔ “MID” ↔ “MID” ↔
“MID” ↔ “TREBLE” ↔
“TREBLE” ↔ “TREBLE”
∗ The factory default setting is “BASS G”.
3-3. Press the [
w] or [z] button to select the
setting.
BASS:The factory default setting is “0”.
(Adjustment range: +7 to – 7)
BASS: The factory default setting is “50”.
(Adjustment range: 50/100/200)
BASS:The factory default setting is “1”.
(Adjustment range: 0.7/1/1.4/2)
MID : The factory default setting is “0”.
(Adjustment range: +7 to -7)
MID : The factory default setting is “500”.
(Adjustment range: 500/1K/2K)
MID : The factory default setting is “1”.
(Adjustment range: 0.7/1/1.4/2)
TREBLE:The factory default setting is “0”.
(Adjustment range: +7 to -7)
TREBLE:The factory default setting is
“10K”.
(Adjustment range: 5K/10K/15K)
TREBLE:The factory default setting is “1”.
(Adjustment range: 0.7/1/1.4/2)
3-4. Press the [ ] button to return to the
previous mode.
● Setting the MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low frequencies like the normal sound
adjustment function, but emphasizes the deep
bass frequencies to provide you with a dynamic
sound.
∗ The factory default setting is “OFF” (off).
2-1. Select “M-B EX”.
3-1. Press [
w] or [z] button to select “ON” or
“OFF”.
● Adjusting the balance
2-1. Select “BALANCE”.
3-1. Press the [
w] or [z] button to adjust the
balance of the right and left speakers.
∗ The factory default setting is “CENTER”
(center). (Adjustment range: RIGHT12 to
LEFT12 (right 12 to left 12))
● Adjusting the fader
2-1. Select “FADER”.
3-1. Press the [
w] or [z] button to adjust the
balance of the rear and front speakers.
∗ The factory default setting is “CENTER”
(center). (Adjustment range: FRONT12 to
REAR12 (front 12 to rear 12))
● Setting the subwoofer
You can set the low pass filter of subwoofer.
This adjustment can be performed only when
the “REAR/S-W” is set to “S-WOOFER”.
2-1. Select “LPF”.
