16
Installing AC Power Supplies in Cisco 3725 Routers
78-13820-01
Replacing the Cisco 3725 Power Supply
Replacing the Router Cover
After you finish replacing the power supply, follow these steps to replace the cover:
Step 1 Place the chassis bottom so the front panel is closest to you.
Step 2 Hold the cover so the tabs at the rear of the cover are aligned with the chassis bottom.
Step 3 Push the cover toward the rear, making sure that the cover tabs fit under the chassis back panel, and the
back panel tabs fit under the cover.
Step 4 Slide the cover slightly to the left to lock the cover into position (number 1 in Figure 10 ).
Figure 10 Replacing the Cisco 3725 Router Cover
Step 5 Lower the front of the cover onto the chassis (number 2 in Figure 10 ).
Step 6 Fasten the cover with the five screws you set aside earlier.
Step 7 Reinstall the chassis on a rack.
Step 8 Reinstall network interface cables.
62492
1
2
