Installation Manual 9 EN
Accessing the SD card
Insert a Micro SD card up to 32GB for local storage as a backup in case the
network fails, for example (see Figure 1 on page 6). The card is not supplied with
the camera.
Video and log files stored on the Micro SD card can only be accessed via the
Web browser. You cannot access the card using TruVision Navigator or a
recording device.
Note: There is no Micro SD card slot in the bullet cameras.
Mounting the dome camera
Mount the dome camera on a ceiling or wall.
To mount the dome on a ceiling:
1. Use the supplied template to mark out the mounting area. Drill the screw
holes on the ceiling. If you need to route the cables from the camera base,
cut a cable hole in the ceiling.
Cable hole
2. Secure the housing to the ceiling with screws.
3. Loosen the screws on the dome enclosure (1) using the supplied hex
wrench and remove the enclosure and the dome liner (2).
