TruVision TVD-6120VE-2 / TVD-6125VE-2 Camera User Manual 7
Programming
Once the camera hardware has been installed, the camera can then be
configured.
Program the camera by attaching a standard video monitor to the system.
To connect the monitor:
1. Plug the monitor output cable to the video monitor output connector.
2. Connect the BNC cable to the video monitor.
3. Press Enter on the OSD menu button to display the Setup menu. See Table
1 for instructions on how to move the cursor.
OSD control button
The on-screen display (OSD) control button (see Figure 1) is a five-direction
joystick that lets you manually control the camera functions. Table 1 below lists
the OSD control button functions and describes their use.
Table 1: Using the OSD control button
Button direction Description
Up Moves the cursor upward to select an item
Left Moves the cursor left to select or adjust the parameters of the selected
item.
Right Moves the cursor to the right to select or adjust the parameters of the
selected item.
Down Moves the cursor downward to select an item.
Enter Press the center of the button to display the Setup menu. If the selected
item has its own menu, press the button to enter a submenu.
Access the Setup menu
The Setup menu provides access to the camera configuration options.
