10 of 12 P/N 1069680 • REV 1.0 • ISS 14APR10
Camera Fault Protection 2 A, 5 x 20 mm type T fuse (front panel access) plus a 2.5 A self-resetting
fuse per channel
Main Fuse 4 A at 115 VAC/3 A at 220 VAC, 5x20 mm, (GEC-8VPDCHUB)
7 A at 115 VAC/5 A at 220 VAC, 5x20 mm, (GEC-16VPDCHUB)
Connectors Camera connection: RJ-45 connector
Data: RJ-45 connector
Video: RJ-45 connector
Power: Detachable terminal blocks (GEC-4VDPC, GEC-16VDPC)
Mechanical
Material GEC-4VDPC: Extruded Aluminum
GEC-16VDPC: Extruded Aluminum
GEC-8VPDCHUB: Extruded Aluminum and sheet metal
GEC-16VPDCHUB: Extruded Aluminum and sheet metal
Dimensions (W x H x D) GEC-4VDPC: 4.97 x 1.74 x 177 in. (12.6 x 4.4 x 4.5 cm)
GEC-16VDPC: 18 x 1.74 x 1.77 in. (46 x 4.4 x 4.5 cm)
GEC-8VPDCHUB: 17 x 1.74 x 10.5 in. (43 x 4.4 x 26.6 cm)
GEC-16VPDCHUB: 17 x 1.74 x 10.5 in. (43 x 4.4 x 26.6 cm)
Weight GEC-4VDPC: 0.44 lb. (198 g)
GEC-16VDPC: 1.37 lb. (620 g)
GEC-8VPDCHUB: 14.7 lb. (6.6 kg)
GEC-16VPDCHUB: 22 lb. (10 kg)
Environmental
Humidity 0 to 95%, noncondensing
Temperature Operating: -10° to +50° C
Storage: -30° to +70° C
*Specifications are subject to change without notice.
Included Accessories
(Excluding the GEC-4VDPB and GEC-16VDPC)
• Mounting brackets for front, rear or wall installations
• Rubber feet for desk applications
• (8, 16, or 32) 2 ft. (60 cm) coax jumper cables
