Telnet
Setup
1. Connect
an RJ-45
cable from
the PC to a
Switch port
on the
Managed
Switch.
Figure 4: RJ-45
connection
diagram
PC / Workstation with IE
browser
Managed
switch
IP address:
192.168.0.X
RJ-45 / UTP cable IP address:
192.168.0.100
2. Launch the Hyper Terminal program. A terminal program is required
to make the software connection to the Managed Switch. Windows'
Hyper Terminal program is a good choice. Hyper Terminal can be
accessed from the Start menu. Click START, then Programs,
Accessories and then Hyper Terminal.
3. The following screen will appear. Input a new connection name. You
should use something like the model name of your switch.
Figure 5: The New Connection dialog window
6 of 11 P/N 1069669-EN • REV 1.01 • ISS 19AUG10
