IFS MC251-4P/1S and NS2051-4P/1T User Manual 19
Network cables
1 . 10/100Base-TX:
Cat. 3, 4, 5, 5e, 6 UTP cable (100meters max.)
2. EIA/TIA-568 100-ohm STP (100meters max.)
Standards Conformance
Standards
Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3af Power over Ethernet
Temperature
Operating: -40 to 75 Degree C
Storage: -40 to 85 Degree C
Humidity Operating: 5~90%, Storage: 5~90% (Non-condensing)
Regulation
Compliance
FCC Part 15 Class A, CE
Stability testing
IEC60068-2-32 (Free Fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
Model NS2051-4P/1T
Hardware Specification
10/100Base-TX Ports
100Base-FX interface
IEEE 802.3af PoE
ports
4
1
4
Dimensions (W x D x
H)
135mm x 87.8mm x 56mm
Weight 842g
Power Requirement 24 or 48V DC
Installation DIN Rail Kit and Wall Mount Ear
Power over Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / PSE
PoE Power Supply End-Span
