D1000

A

B

C

D

E

F

1 2 3 4 5 6 7 8

B

A

C

Data Receive

Data Transmitter

Data Receiver

LED illuminates

D Data Transmit

LED illuminates

E Data / Power Connector

F Power

LED illuminates

NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.
