Interlogix D1000 Series User Manual
Page 3
ifs
International
Fiber
Systems
Incorporated
XTMR
RS422
RS232
RS422
REC
D1010
RS232/RS422 TRANSCIEVER
8
+ DATA IN
7
- DATA IN
6
+ DATA OUT 5
- DATA OUT 4
RS232 OUT 3
2
+ 12 VDC
1
POWER
Duplex multimode
fiber optic cable
To D1000 or
D2100 series module
RS232 Input (Pins 7 and 8)
RS422 Output (Pins 4 and 5)
RS232 Output (Pins 3 and 8)
Black wire
Black with white stripe
RS422 Input (Pins 6 and 7)
}
TRANSMIT
RECEIVE
Signal Ground
