IC Realtime 1080P (Full HD over coax) HD-SDI / HDcctv 20x Optical PTZ User Manual
Page 24
18
Move the cursor to highlight CRUISE item and then click confirm button to go to set interface.
z
CRUISE
NO
：Here is to ser tour number. The value ranges from 1 to 8. Please use the left/right button
on the keyboard or in the speed dome terminal menu to set.
z
CRUISE SETTING: Move the cursor to cruise setting item and then click confirm button. You can see
the following interface. Here you can add or remove the preset, and set the corresponding dwell time
and call speed. One cruise can max have 32 presets. The preset value ranges from 0 to 255. The dwell
time ranges from 3 to 255. The speed ranges from 1 to 16.
DWELL: Here is t set dwell time. Please use the left/right button on the keyboard or in the speed
dome terminal menu to set.
SPEED: Here you can set the speed value.
When you move the cursor to one cruise number, you can use left/right button to turn the page.
When you move the cursor to one cruise number, please click confirm button to set the cruise. Please use
up/down button to set preset number, dwell time and speed. Use the left/right button to go to the next cruise.
Click confirm button you can exit the setup. After you completed the setup, move the cursor to back button
to go to the previous interface.
z
DELETE
CRUISE
：Here is to delete a cruise. Input cruise number in CRUISE NO and then move the
cursor to DELETE cruise, click confirm button to delete.
z
CALL: Here is to activate cruise. Input touring number in touring NO and highlight CALL, click confirm
button to activate touring.
z
STOP: Here is to terminate touring.
z
BACK: Go back to previous menu.
z
EXIT: Log out system menu.
3.4.4.5 Pattern
Pattern function can memory PTZ operation and camera focus zoom in and zoom out.
From the start position, dome begins auto movement repeatedly.
This series IP dome supports maximum 5 patterns and one pattern can max support 400 commands.
PATTERN NO: 001
PROGRAM START
PROGRAM STOP
RUN
STOP
BACK
EXIT
NO PRESET DWELL SPEED
01 000 005 013
02 000 005 013
03 000 005 013
… … … …
32 000 005 013
