2 Framework
2.1 Rear Panel
This series camera real panel is shown as below. See Figure 2-1.
Figure 2-1
Please refer to the following sheet for detail information.
Interface Name
Connector
Function
AC 24V/ DC 12V
Power port
z
Power
port.
z
Input 12V DC or
AC 24V
STATUS
Indication Light
Red light
z
The red light is on
when the system
is working
properly.
z
It
flashes
when
the system is
upgrading.
