2 side panel, 3 lens – IC Realtime HD-SDI High performance processor camera User Manual
Page 10
10
for at least 5
seconds, system
can restore
factory default
setup. Yellow light
flikers.
HD-SDI
Send out the SDI
video stream
conforming to the HD-
SDI specifications.
GND
Please make sure the
device is securely
earthed to prevent the
thunderstorm strike.
2.2 Side Panel
Please refer to the following interface for side panel dimension information. The unit is mm. See
Figure 2-2.
Figure 2-2
2.3 Lens
Please refer to the following interface for lens dimension information. The unit is mm. See Figure
2-3.
