1 General Introduction
1.1 Overview
This series camera conforms to the HD-SDI specifications. It supports high speed video signal,
almost no delaying in the transmission. The HD-SDI interface adopts the coaxial cable and uses
the BNC port as the cable standard.
This series product has the Megapixel definition and supports the DC 12V/AC 24V power.
1.2 Feature
Data
Transmission
z Adopt coaxial cable. Use the BNC port as the cable standard.
Peripheral
Equipment
z Support peripheral equipment connection via the RS485 port, each
peripheral equipment control protocol and interface can be set freely.
Power
z External power adapter. Support DC 12V/AC 24V power supply.
Assistant
Function
z Day/Night mode auto switch (ICR switch.)
z Backlight compensation: screen auto split to realize backlight
compensation to adjust the bright.
z Support auto iris function.
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for performance specification.
Model
Parameter
HDC-HF3300P/N
Syst em
Main
Processor High performance processor
Image Sensor
1/2.8-inch CMOS
Pixel 2048（H）*1536（V）
Day/Night
Mode
Support day/night mode switch and IR-CUT at the same time.
Auto Iris DC drive
Gain Control Fixed/Auto
White Balance
Manual/Auto
Exposure
Mode
Manual/Auto（It ranges from 1/50 to 1/10000）
Video Frame
Rate
Conform to the SDI specifications SMPT274/292 protocol
Video Bit Rate
PAL: 1920*1080@25fps；NTSC:1920*1080@30fps
Video Mirror Support mirror, support negative image.
Video Setup Support parameter setup such as brightness, contrastness.
Video
Information
OSD menu
Lens Provided
Video Parameter
Lens Interface C/CS optional
