Key A: 5 Flat Washer – 2Pcs.
Key C: No:10-24UNC X 10 – 2PCs.
Key E: 1/4”-20UNC Nut – 2Pcs.
Key G: 1/4” x 13 Screw – 14 Pcs.
Key I: ST4.2 x 10 Tapping Screw – 2Pcs.
Key B: 5 Lock Washer – 2 Pcs.
Key D: 19 Washer – 2Pcs.
Key F: 7 Flat Washer – 14 Pcs.
Key H : 7 Lock Washer – 14 Pcs.
A S S E M B L Y I N S T R U C T I O N S Tools Needed for Assembly
• #2 Phillips ® screwdriver
• 1/4˝ slotted screwdriver
• Adjustable wrench
• Pliers
• Rubber mallet
Before assembling the barbecue, read these
instructions carefully. Assemble the barbecue
on a flat, clean surface.
Notes: Do not fully tighten all
the nuts during this initial stage.
