GTCO Summagrid V Commands - Manual (Page 10)

ESC C 3
ESC C 4
ESC C 5
ESC C 6
ESC C 7
ESC C 8
ESC C 9
ESC C A
ESC C B
ESC T 0
ESC T 1
ESC t
ESC a
ESC G
ESC w
SET RESOLUTION TO 1016 LPI, 40 LPmm
SET RESOLUTION TO 500 LPI
SET RESOLUTION TO 508 LPI, 20 LPmm
SET RESOLUTION TO 400 LPI
SET RESOLUTION TO 100 LPI
SET RESOLUTION TO 1 LPI
SET RESOLUTION TO 2 LPI
SET RESOLUTION TO 4 LPI
SET RESOLUTION TO 4096/LONG AXIS
CLR TABLET ID
SET TABLET ID
DO SELF TEST
SEND SIZE
PROMPT COMMAND
SEND SELF TEST
7 6 5 4 3 2 1 0LSB
P X 0 1 X X 1 1
| | +------- DIGITAL TEST 0=ERROR
| +---------- PROXIMITY (1= IN 0=OUT)
+------------------- TOTAL ERROR FLAG
ESC x RETURN CHECK SUM
Lectra changes
first byte of format 31 is 40h rather than 48h
cording is allowed on the pen in format 31
data is sign magnitude on format 31
no cr on "w" test mode
after dpoint (locate origin command) do not clear pen down and convert flag so "request or
mode will return a point
add Xn command that does nothing
force run prompt on bad M (mode)commands
