The stabilizer and wing incidences and engine thrust
angles have been factory-built into this model. However,
some technically-minded modelers may wish to check
these measurements anyway. To view this information
visit the web site at www.greatplanes.com and click on
“Technical Data.” Due to manufacturing tolerances which
will have little or no effect on the way your model will fl y,
please expect slight deviations between your model and
the published values.

ORDERING REPLACEMENT PARTS

Replacement parts for the Great Planes Sukhoi SU-31
1.60 ARF are available using the order numbers in the
Replacement Parts List that follows. The fastest, most
economical service can be provided by your hobby dealer or
mail-order company.

To locate a hobby dealer, visit the Hobbico

®

web site at

www.hobbico.com. Choose “Where to Buy” at the
bottom of the menu on the left side of the page. Follow the
instructions provided on the page to locate a U.S., Canadian
or International dealer.

Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa

®

or MasterCard

®

number and expiration date for payment.
Mail parts orders and payments by personal check to:

Hobby Services

3002 N. Apollo Drive, Suite 1

Champaign, IL 61822

Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment is by credit card or
personal check only; no C.O.D.

If additional assistance is required for any reason contact Product
Support by e-mail at [email protected],
or by telephone at (217) 398-8970.

Replacement Parts List

GPMA3070 Wing

Kit

GPMA3071 Fuse

Kit

GPMA3072 Tail

Set

GPMA3073 Cowl
GPMA3074 Canopy
GPMA3075 Landing

Gear

GPMA3076 Wheel

Pants

GPMA3077 Decals
GPMA3078 Spinner

COMMON ABBREVIATIONS

Fuse = Fuselage

Stab = Horizontal Stabilizer

Fin = Vertical Fin

LE = Leading Edge

TE = Trailing Edge

LG = Landing Gear

Ply = Plywood

" = Inches

mm

=

Millimeters

SHCS = Socket Head Cap Screw

ESC = Electronic Speed Control

METRIC CONVERSIONS

1

" = 25.4mm (conversion factor)

1/64" = .4mm

1/32" = .8mm

1/16" = 1.6mm

3/32" = 2.4mm

1/8" = 3.2mm

5/32" = 4.0mm

3/16" = 4.8mm

1/4" = 6.4mm

3/8" = 9.5mm

1/2" = 12.7mm

5/8" = 15.9mm

3/4" = 19.0mm

1" = 25.4mm

2" = 50.8mm

3" = 76.2mm

6" = 152.4mm

12" = 304.8mm

18" = 457.2mm

21" = 533.4mm

24" = 609.6mm

30" = 762.0mm

36" = 914.4mm
