4
❏
Great Planes Gold Plated Bullet Connectors Male
4mm (GPMM3114)
❏
W.S. Deans ® Racing Silver Solder 1 oz. (WSDC4030)
❏
Hobbico ® Soldering Iron 60 Watt (HCAR0776)
Batteries & Charger
For a brushless out-runner motor installation, a 3200mAh
11.1V Lithium-Polymer battery pack or a 2000mAh 9.6V
NiMH pack are recommended. Order numbers for the battery
packs are provided below:
❏
Great Planes LiPo 3200mAh 11.1V 20C Discharge
w/Balance (GPMP0623)
❏
Great Planes 8-Cell 9.6V 4/5 SC 2000mAh NiMH
Custom (GPMP0352)
Note: A cell balancer is required for the LiPo battery pack
listed above.
❏
Great Planes ElectriFly ™ Equinox LiPo 1 to 5 Cell
Balancer (GPMM3160)
A suitable charger is also required. The Great Planes
PolyCharge4
™ is designed for LiPo packs only, but is able
to charge four LiPo packs simultaneously. The Great Planes
Triton2
™ charger will only charge one pack at a time, but
is capable of charging NiCd, NiMH, LiPo, and lead acid
batteries. Order numbers for both are provided below:
❏
Great Planes PolyCharge4 DC Only 4 Output LiPo
Charger (GPMM3015)
or
❏
Great Planes ElectriFly Triton ™ 2 DC Comp Peak
Charger (GPMM3153)
For an economical alternative to charge NiMH packs,
we suggest:
❏
Great Planes ElectriFly Peak 400 DC 1-10C Peak
Charger (GPMM3001)
Propeller
If using the O.S. .25 FX glow engine or the Great Planes
35-30-1450kV RimFire out-runner motor, we suggest using
a 9" x 6" propeller.
❏
APC 9" x 6" sport propeller (APCQ0906)
ADDITIONAL ITEMS REQUIRED
Required Hardware & Accessories
This is the list of hardware and accessories required to
fi nish the P-40 Warhawk ARF. Order numbers are provided
in parentheses:
❏
R/C foam rubber (1/4" [6mm] – HCAQ1000, or 1/2"
[13mm] – HCAQ1050)
❏
3' [900mm] Standard silicone fuel tubing (GPMQ4131)
Adhesives & Building Supplies
This is the list of Adhesives and Building Supplies that are
required to fi nish the P-40 Warhawk ARF:
❏
1/2 oz. [15g] Thin Pro ™ CA (GPMR6001)
❏
1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
❏
Pro 30-minute epoxy (GPMR6047)
❏
Masking tape (TOPR8018)
❏
Threadlocking compound (GPMR6060)
❏
Denatured alcohol (for epoxy clean up)
❏
Drill bits: 1/16" [1.6mm], 5/64" [2mm], 1/8" [3.2mm]
❏
Great Planes 10-piece metric tap & drill set
(GPMR8118, Note: 3mm tap & drill is needed for glow
engine installation only)
❏
Tap handle (GPMR8120)
❏
R/C-56 canopy glue (JOZR5007)
❏
Small metal fi le
❏
220-grit Sandpaper
❏
Panel Line Pen (TOPQ2510)
❏
#1 Hobby knife (HCAR0105)
❏
#11 Blades (5-pack, HCAR0211)
❏
Medium T-pins (100, HCAR5150)
❏
Top Flite ® MonoKote ® sealing iron (TOPR2100)
❏
Top Flite Hot Sock ™ iron cover (TOPR2175)
❏
Liquid dish soap
Optional Supplies & Tools
Here is a list of optional tools that will help you build the P-40
Warhawk ARF:
❏
1/2 oz. [15g] Thick Pro CA- (GPMR6013)
❏
2 oz. [57g] Spray CA activator (GPMR6035)
❏
4 oz. [113g] Aerosol CA activator (GPMR6034)
❏
CA applicator tips (HCAR3780)
❏
CA debonder (GPMR6039)
❏
Pro 6-minute epoxy (GPMR6045)
❏
Epoxy brushes 6, (GPMR8060)
❏
Mixing sticks (GPMR8055)
❏
Mixing cups (GPMR8056)
❏
Pliers with wire cutter (HCAR0630)
