An Electronic Speed Control (ESC) with Battery Eliminator
Circuitry (BEC) is required. The BEC allows both the motor
and the radio system to be powered by the same battery
(thus eliminating the on-board receiver battery). The Great
Planes ElectriFly C-7 Nano Brushed ESC (GPMM2005)
is recommended.
❏
Great Planes Pro ™ Foam Safe CA- Thick Glue
1 oz. (GPMR6072)
❏
Great Planes Pro Foam Safe CA+ Medium Glue
1 oz. (GPMR6069)
❏
Drill bits: 3/64" [1.2mm] or #60 and 1/8" [3mm]
❏
#1 Hobby knife (HCAR0105)
❏
Hobbico ® soldering iron 60 Watt (HCAR0776)
Here is a list of optional tools that will help you build the
FlatOuts J-3 Cub.
❏
Great Planes Pro Foam Safe CA Aerosol Activator
4 oz. [114g] (GPMR6034)
❏
2 oz. [57g] Spray CA activator (GPMR6035)
❏
CA applicator tips (HCAR3780)
❏
CA debonder (GPMR6039)
❏
Hobbico Pin Vise 1/16" Collet w/six bits (HCAR0696)
❏
Long nose pliers with wire cutter (HCAR0625)
❏
CG Machine ™ (GPMR2400)
❏
Hobbico Flexible 18" Ruler Stainless Steel (HCAR0460)
• When you see the term test fit in the instructions, it
means that you should first position the part on the
assembly without using any glue, and then slightly modify
or
custom fit the part as necessary for the best fit.
• Whenever the term glue is written you should rely upon
your experience to decide what type of glue to use. When a
specific type of adhesive works best for that step, the
instructions will make a recommendation.
• Photos and sketches are placed before the step they
refer to. Frequently you can study photos in following steps
to get another view of the same parts.
Replacement parts for the Great Planes FlatOuts J-3 Cub are
available using the order numbers in the Replacement Parts
List that follows. The fastest, most economical service can be
provided by your hobby dealer or mail-order company.
To locate a hobby dealer, visit the Hobbico web site at
www.hobbico.com. Choose “Where to Buy” at the bottom
of the menu on the left side of the page. Follow the
instructions provided on the page to locate a U.S., Canadian
or International dealer.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa
® or MasterCard ®
number and expiration date for payment.
Mail parts orders and payments by personal check to:
Hobby Services
3002 N. Apollo Drive, Suite 1
Champaign, IL 61822
Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment by credit card or
personal check only; no C.O.D.
If additional assistance is required for any reason contact Product
Support by e-mail at [email protected],
or by telephone at (217) 398-8970.
Replacement Parts List
GPMG0420 ............180 Motor & 5:1 Ratio Gearbox
GPMG0292 ............180 Motor with Leads & Connectors
GPMG0182 ............Gearbox with Spur Gear Shaft 5:1 Ratio
GPMG0863 ............Spur Gear Shaft
GPMQ4619 ............Prop Saver O-ring
GPMQ4620 ............Prop Saver
Fuse = Fuselage
Stab = Horizontal Stabilizer
Fin = Vertical Fin
LE = Leading Edge
LG = Landing Gear
" = Inches
mm = Millimeters
ESC = Electronic Speed Control
COMMON ABBREVIATIONS
ORDERING REPLACEMENT PARTS
IMPORTANT BUILDING NOTES
