14 VMA6593
6. TROUBLESHOOTING
No picture.
Press the [SOURCE] button to make sure the proper input is
selected.
If there is still no picture, press the [PICTURE ] button. If the
menu appears, check the source unit and video connections.
If no menu appears, check all fuses and power connections
to the VMA6593 and the associated equipment.
Note:
•
The VMA6593 has an operating temperature range of
-1 o C to 45 o C (30 o F - 113 o F). If the temperature is outside this
operating range, the unit will not turn on, or the screen
may be slow to react to image changes. The monitor will
function normally once it returns to its proper operating
range.
With a DVD player and a widescreen DVD disc, there are
black bars on the screen.
Change the TV display mode to “Wide” in the DVD player’s
Setup menu.
After changing this setting, if there are still black bars, press
the [WIDE] button on the front panel of the VMA6593.
7. SPECIFICATIONS
Supply voltage: 12V DC (9V-16V)
Test voltage: 12V, negative ground
Current consumption: Less than 750 milliAmps
Operating Temperature: -1 o C to 45 o C (30 o F to 113 o F)
Signal system: NTSC and PAL composite video 1.0Vp-p
Screen: 6.5” diagonal, 144.4mm x 80.3 mm.
Resolution: 1200 x 280 (280,000 pixels)
Weight: 0.5 kg
Note:
• The technical data and the design of the equipment may change
for the sake of technical improvements without prior notice.
