Page 14 of 20 CDI-9323 User Manual
••••
(V 0.5)
Src Output Source
Gain Output Gain
Ch10
Pol Output Polarity
Src Output Source
Gain Output Gain
Ch11
Pol Output Polarity
Src Output Source
Gain Output Gain
Ch12
Pol Output Polarity
Src Output Source
Gain Output Gain
Ch13
Pol Output Polarity
Src Output Source
Gain Output Gain
Ch14
Pol Output Polarity
Src Output Source
Gain Output Gain
Ch15
Pol Output Polarity
Src Output Source
Gain Output Gain
Ch16
Pol Output Polarity
Disp H/V Display Orientation
BRGT Display Brightness
Prst Save Save Settings
Load Load Settings
Fact Restore Factory Settings
Parameter Type Descriptions
Output Source
Because the cards audio system functions like a router, each AES output can be sourced from any AES
input channel.
Output Gain
The gain of each output is adjustable from +30 dB to –100 dB in 0.1 dB steps. After –100 dB gain is
set to –Inf, which means that output is present, but muted.
Output Polarity
If set to “Norm” output polarity is the same as input polarity, if set to “Inv” the output polarity is
inverted. This can be used to correct polarity errors in the input signals fed to the card.
Display Orientation
This parameter lets you change the orientation of the display. “Vert” makes the characters look correct
when the cards are mounted in a 2 RU frame like the 8310. “Horz” makes the characters look right in a
horizontal frame.
Display Brightness
This parameter allows you to set the standard output brightness of the menu display. It is a percentage
of maximum brightness.
