Power Systems
Good: GPMG0755 S-600 Motor System
S-600 motor (GPMG0710)
8 x 4 propeller
Propeller adapter
Wiring harness with fuse and micro switch
Better: GPMG0760 T600GD System with Gear Drive
T600R reverse rotation motor (GPMG0700)
2.5:1 gearbox (GPMG0850)
Propeller adapter (GPMG0855)
10 x 8 propeller for electrics
Wiring harness with fuse and micro switch
Best: GPMG0760 T600GD ESC System with Gear Drive
and electronic speed control
T600r reverse rotation motor (GPMG0700)
2.5:1 gearbox (GPMG0850)
Propeller adapter (GPMG0855)
10 x 8 propeller for electrics
Speed 300 Electronic speed control with BEC and
auto cutoff (GPMM2030)
These are the building supplies that are required. We
recommended Great Planes Pro
™ CA and Epoxy glue.
❏ 1 oz. Thin Pro ™ CA (GPMR6002)
❏ 1 oz. Medium Pro CA (GPMR6008)
❏ 6-Minute Pro Epoxy (GPMR6045)
❏ 30-Minute Pro Epoxy (GPMR6047)
❏ Thread locking compound (GPMR6060)
❏ Balsa filler (HCAR3401)
❏ Plan protector (GPMR6167)
❏ Isopropyl rubbing alcohol (70%)
❏ Paper towels
❏ Sanding block and sandpaper (coarse, medium, fine)
❏ Hobby knife (HCAR0105)
❏ #11 blades (HCAR0211)
❏ Single-edge razor blades (HCAR0212)
❏ Razor saw
❏ Razor plane (MASR1510)
❏ Electric drill
❏ Drill bits - 1/16", 3/32", 7/64", 1/8", 5/32", 11/64", 3/16"
❏ Small Phillips and flat blade screwdrivers
❏ Pliers with wire cutter (HCAR0630)
❏ Sealing iron (TOPR2100)
❏ Heat gun (TOPR2000)
❏ T-Pins (HCAR5150)
❏ Straightedge with scale (HCAR0475)
❏ Cutting mat (HCAR0456)
❏ Builder’s triangle (HCAR0480)
❏ 10-24 Tap and Drill set
❏ Masking tape (TOPR8018)
❏ Panel line pen (TOPQ2510)
❏ CG Machine ™ (GPMR2400)
❏ Accu Throw ™ Deflection Meter (GPMR2405)
❏ CA Applicator tips (HCAR3780)
❏ CA Debonder (GPMR6039)
❏ Clevis installation tool (GPMR8030)
❏ Hot Sock ™ (TOPR2175)
❏ Curved-tip canopy scissors (HCAR0667)
❏ Top Flite Precision Magnetic Prop Balancer ™ (TOPQ5700)
❏ Slot Machine ™ motorized hinge slotting tool (GPMR4010)
❏ Precision hinge marking tool (GPMR4005)
❏ Groove tube (GPMR8140)
Great Planes Easy-Touch Bar Sanders are made from
lightweight extruded aluminum and can be found at most
hobby shops. They are available in five sizes.
5-1/2” (GPMR6169) for those tight, hard-to-reach spots;
11” (GPMR6170) for most general purpose sanding;
22” (GPMR6172), 33” (GPMR6174) and 44” (GPMR6176)
for long surfaces such as wing leading edges. The Easy-
Touch Adhesive-Backed Sandpaper comes in 2” x 12’
rolls of 80-grit (GPMR6180), 150-grit (GPMR6183) and
220-grit (GPMR6185) and an assortment of 5-1/2” long
strips (GPMR6189) for the short bar sander. The adhesive-
backed sandpaper is easy to apply and remove from your
sanding bar when it’s time for replacement.
Custom sanding blocks can be made from balsa or
hardwood blocks and dowels for sanding difficult-to-
reach spots.
On our workbench, we have three 11” Great Planes
Easy-Touch
™ Bar Sanders, equipped with #80, #150
and #220-grit sandpaper. This setup is all that is required
for almost any sanding task. We also keep some
#320-grit wet-or-dry sandpaper handy for finish sanding
before covering.
Optional Supplies and Tools
Tools
Building Supplies
