KIT CONTENTS

Before starting to build, use the Kit Contents list to take an inventory of this kit to make sure it is complete, and inspect
the parts to make sure they are of acceptable quality. If any parts are missing or are not of acceptable quality, or if you need
assistance with assembly, contact Great Planes Product Support. When reporting defective or missing parts, use the part
names exactly as they are written in the Kit Contents list on this page

Great Planes Product Support:

Phone: (217) 398-8970

Fax: (217) 398-7721

E-mail: [email protected]

1. R & L Wing panels w/ailerons
2. Fuselage
3. Stab w/elevators
4. Fin w/rudder
5. Canopy
6. (2) Painted wheel pants
7. (2) Main landing gear wires

Kit Contents (Photographed)

8. (2) 1/8" [3.2mm] Plywood wing joiners
9. Aileron servo mount
10. Elevator joiner wire
11. (2) 1/8" [3.2mm] Plywood inner

wheel pant mounts

12. Fuel tank w/hardware
13. Tail gear w/tail wheel

14. Great Planes .40 – .70 adjustable

engine mount

15. (2) 2-3/4" [70mm] Wheels
16. Spinner

(4) 6-32 x 3/4" [19mm] SHCS (socket-head cap

screws, engine mount to firewall)

(4) #6 Lock washers (engine mount to firewall)
(4) #6 Flat washers (engine mount to firewall)
(4) 4-40 x 3/4" [19mm] SHCS (engine to mount)
(4) #4 Lock washers (engine to mount)
(4) #4 Flat washers (engine mount)
(2) Tree of 4 nylon straps (wheel pants-2,

landing gear-4)

(8) #2 x 1/2" [13mm] Screws (landing gear straps)
(4) #2 x 3/8" [9.5mm] Screws (wheel pant straps)
(4) 5/32" [4mm] Wheel collars (main wheels)
(4) 6-32 Set screws (for wheel collars)
(1) Prebent tail gear wire w/nylon bearing mount
(1) 1" [25mm] Tail wheel
(1) 3/32" [2.4mm] Wheel collar (tail wheel)
(1) 4-40 Set screw (tail wheel)

Kit Contents (Not Photographed)

(4) Faslinks (ailerons-2, elevator, rudder)
(5) Nylon clevis (ail.-2, throt, rudd, elev)
(5) Silicone retainers (clevises)
(2) 4-40 Nylon torque rod horn (ailerons)
(2) Large control horns (elev., rudd.)
(4) 2-56 x 1/2" [13mm] Phillips screws (control horns)
(1) Brass body screw-lock connector (throttle servo)
(1) 4-40 x 1/4" [6mm] SHCS (screw-lock connector)
(1) Nylon retainer (screw-lock connector)
(2) .074" x 36" [2 x 910mm] Threaded one-end

pushrod wire (elevator, rudder)

(2) .074" x 6" [2 x 150mm] Threaded one-end

pushrod wire (ailerons)

(1) .074" x 17-1/2" [2 x 445mm] Threaded one-

end pushrod wire (throttle)

(1) 3/16" x 12" [4.8 x 300mm] Guide tube (throttle)
(1) 2" x 9" [50 x 230mm] CA hinge strip

(2) 1/4-20 x 2" [50mm] Nylon wing mounting bolts
(2) 3/16" X 36" [ 4.8 x 910mm] Pushrod guide

tubes (preinstalled, elevator/rudder)

(2) 1/4-20 Blind nuts (preinstalled, wing mount)
(1) Decal sheet
