7. Cut an 8" [200mm] piece of pushrod string. Loop it
through the forward hole and around the carbon fuse and
the elevator turnaround twice. Pull elevator turnaround to
the fuse with the string and secure with thin CA.
❏
8. Pull the remaining string through the rear hole and loop it
around the fuse and elevator turnaround as many times as
possible. Pull the string tight and secure it with thin CA.
❏❏
9. Glue the stab to the fuse, making sure it is aligned
with the wing and that the TE of the elevator is 1/8" [3mm]
in front of the fin.
❏
1. Trim the covering and slide the two sided plywood
control horn through the rudder, center it and then glue it
with thin CA.
❏
2. Slide the single sided plywood control horn into the
elevator and glue with thin CA.
❏
3. Install the aileron extensions under the servo tray.
A. If you will be utilizing flaperon mixing install two
12" [300mm] servo leads.
OR
B. If you will be using the ailerons just as ailerons
install a Y-harness.
Install the Rudder & Elevator Servos
