4
ADDITIONAL ITEMS REQUIRED
Required Adhesives & Building Supplies
This is the list of adhesives and building supplies required to
fi nish the Factor 3D EP ARF. Order numbers are provided in
parentheses.
❍ 1/2 oz. [15 g] Thin Pro CA (GPMR6001)
❍ 1/2 oz. [15 g] Medium Pro CA+ (GPMR6007)
❍ Drill bits: 1/16" [1.6 mm], 5/64" [ 2 mm]
❍ #1 Hobby knife (HCAR0105)
❍ #11 blades (5-pack, HCAR0211)
❍ Small T-pins (100, HCAR5100)
Optional Supplies and Tools
Here is a list of optional tools mentioned in the manual that
will help you build the Factor 3D EP ARF 580 EP.
❍ Pro 30-minute epoxy (GPMR6047)
❍ Denatured alcohol (for epoxy clean up)
❍ 2 oz. [ 57g] spray CA activator (GPMR6035)
❍ CA applicator tips (HCAR3780)
❍ CA debonder (GPMR6039)
❍ Epoxy brushes (6, GPMR8060)
❍ Mixing sticks (50, GPMR8055)
❍ Mixing cups (GPMR8056)
❍ Threadlocker thread locking cement (GPMR6060)
❍ AccuThrow
™ Defl ection Gauge (GPMR2405)
❍ CG Machine ™ (GPMR2400)
❍ 21
st Century ® sealing iron [COCR2700]
❍ 21 st Century iron cover [COVR2702]
IMPORTANT BUILDING NOTES
● There are two types of screws used in this kit:
Sheet Metal Screws are designated by a number and a
length. For example #6

3/4" [19mm].
This is a number six screw
that is 3/4" [19 mm] long.
Machine Screws are designated by a number,
threads per inch, and a length. For example
4-40

3/4" [19mm].
This is a number four screw
that is 3/4" [19 mm] long with
forty threads per inch.
● When you see the term test fi t in the instructions, it means
that you should fi rst position the part on the assembly
without using any glue, then slightly modify or custom
fi t the part as necessary for the best fi t.
● Whenever the term glue is written you should rely upon
your experience to decide what type of glue to use. When
a specifi c type of adhesive works best for that step, the
instructions will make a recommendation.
● We recommend 30-minute epoxy only, because you will
need the working time or the additional strength
● Photos and sketches are placed before the step they refer
to. Frequently you can study photos in following steps to
get another view of the same parts.
KIT INSPECTION
Before starting to build, take an inventory of this kit to make
sure it is complete, and inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not
of acceptable quality, or if you need assistance with assembly,
contact Product Support. When reporting defective or missing
parts, use the part names exactly as they are written in the
Kit Contents list.
Great Planes Product Support
3002 N Apollo Drive, Suite 1 Ph: (217) 398-8970, ext. 5
Champaign, IL 61822
Fax: (217) 398-7721
E-mail: [email protected]
ORDERING REPLACEMENT PARTS
Replacement parts for the Great Planes Factor 3D EP ARF
are available using the order numbers in the Replacement
Parts List that follows. The fastest, most economical service
can be provided by your hobby dealer or mail-order company.
To locate a hobby dealer, visit the Hobbico web site at www.
hobbico.com. Choose “Where to Buy” at the bottom of the menu
on the left side of the page. Follow the instructions provided
on the page to locate a U.S., Canadian or International dealer.
If a hobby shop is not available, replacement parts may also
be ordered from Tower Hobbies at www.towerhobbies.com,
or by calling toll free (800) 637-6050.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721, but
full retail prices and shipping and handling charges will apply.
Illinois and Nevada residents will also be charged sales tax.
If ordering via fax, include a Visa or MasterCard number and
expiration date for payment.
Mail parts orders Hobby Services
and payments by 3002 N Apollo Drive, Suite 1
personal check to: Champaign IL 61822
