PAGE 18 INSTRUCTION MANUAL TX650
General
Complies with: AS/NZS 4365:00 for radio communications
equipment in the UHf CB and personal radio service.
Frequency Range: 476.45 ‑ 477.400 MHz
Number of Channels: 40 (38 Voice and Telemetry receive channels)
Channel Spacing: 5 kHz
Operating Mode: Simplex or half duplex
Privacy Codes: 38
Operating Temperature: ‑ 10˚C to + 60˚C
Battery Source: Li‑Ion 3.7 V DC 70 mAh rechargeable battery pack
Operating Time: 10 Hrs (Transmit 5%, Receive 5%, Standby 90%)
Transmitter
RF Output: Hi ‑ 1 Watt Low ‑ 0.5 Watts
Modulation: fM
Max. Deviation: ± 5 kHz
Modulation Distortion: < 5% (1 kHz 70%)
Receiver
Usable Sensitivity: > ‑ 118 dBm
Maximum Audio Output: > 0.3 Watts maximum (8 Ohms)
Modulation Distortion: < 5% (1 kHz 70%)
Specifications are typical unless otherwise indicated and may be subject to change without
notice or obligation.
TeChNICAL SpeCIFICATIONS
