PARTS LIST
1 PRODUCT MANUAL, ENGLISH
1 PRODUCT MANUAL, SPANISH
1 HARDWARE PACK
Not Pictured
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
…
…
…
Key Qty Description
A 1 FIREBOX
B 1 VALVE/HOSE/REGULATOR
C 1 CONTROL PANEL
D 2 CONTROL KNOBS
E 1 IGNITOR
F 2 AXLE F/WHEEL
G 1 LEFT CART LEG
H 1 BURNER ASSEMBLY
I 2 WHEELS
J 1 RIGHT CART LEG
K 2 LEG EXTENDER
L 1 BOTTOM SHELF
M 1 BACK SUPPORT BRACE
N 1 TANK RETAINER
O 1 FRONT PANEL
P 1 SIDE SHELF
Q 1 LID
R 1 LOGO PLATE ASSEMBLY
S 1 HANDLE ASSEMBLY
T 1 SIDEBURNER FRAME
U 1 SIDEBURNER PAN
V 1 SIDEBURNER GRATE
W 1 TOOL HOLDER
X 1 SIDEBURNER VALVE CUP
Y 1 SIDEBURNER
Z 1 SIDEBURNER KNOB
AA 1 HEAT TENT
BB 1 COOKING GRATE
CC 1 SWING AWAY
DD 2 LOWER HINGE
EE 2 UPPER HINGE
FF 1 GREASE CUP
GG 1 CLIP, GREASE CUP
HH 1 HEAT SHIELD F/TANK
II 1 HEAT SHIELD F/FIREBOX
JJ 1 MATCH HOLDER
