7 RM-10
Phoenix Block Inputs/Outputs
Two Band EQ:
LOW: +/- 12dB @ 200 Hz
HIGH: +/ - 12dB @ 10kHz
10 Segment VU Meter:
-21dB, -18dB, -15dB, -12dB, -9dB, -6dB, -3dB, 0dB,
+3dB, +6dB
Distortion:
THD 0.05% (22Hz-22kHz @ Nominal Volume)
Noise:
S/N >100dB
Power Requirements:
12V dc at 1.3A, supplied by external power supply
Frequency Response:
20Hz-20kHz +/-3dB
Weight:
4.95 lbs (2.24kg)
Dimensions:
19" L x 1.75" H x 6.25" D
(482.6mm x 44.45mm x 158.75mm)
Pin 1: Ground
Pin 2: +
Pin 3: -
