The NSPA (POWERED NANO SPOT)
CONTROLS/INDICATORS and their operation (Front Panel)
POWER LED
SIGNAL PRESENCE INDICATOR
COMPRESSOR LED
SPEAKER
2 BAND EQ
LEVEL CONTROL
YOKE
BRACKET
MOUNT
YOKE
BRACKET
MOUNT
1/4" LINE INPUT
XLR BALANCED
MIC INPUT
SAFETY CABLE MOUNT
POWER
SWITCH
1/8" LINE INPUT
-20 dB PAD SWITCH (XLR ONLY)
12-18VDC 2A Input
CONTROLS/INDICATORS and their operation (Back Panel)
11
