INSTALLATION:
ATTACHING THE BRACKET ASSEMBLY TO THE MOUNTING SURFACE:
Position the bracket assembly onto the wall or ceiling at the location you have selected, preferably to
a stud, joist or other structural member rather than only to drywall or other non-structural material.
Make sure there will be enough clearance to rotate and tilt the speaker to the desired angle. Using
the base plate of the bracket assembly as a template, mark the four hole locations.
NOTE: Check that any holes you drill and the fasteners will not interfere with any wiring,
plumbing, etc. that may be behind the mounting surface.
Prepare the mounting surface and the four holes for the fasteners. Pull speaker wires through the
mounting surface and the feed thru the hole in the bracket. Secure the bracket base plate. Do not
over tighten fasteners! Bolt the yoke to the base plate and tighten with a 7/16" box end wrench.
JOINING THE CABINET TO THE BRACKET ASSEMBLY:
Remove the two plastic threaded inserts from the T-nuts with a small flat blade screwdriver. Lift the
speaker into position so that the wing screws at the ends of the yoke line up with the T-nuts in the
cabinets. Tighten the wing screws by hand.
SECURING THE SAFETY CABLE:
Slip the loose end of the safety cable through the cable clamp located at the back of the cabinet.
Bring the cable back through the crimp sleeve and firmly crimp the sleeve with a large pair of
crimping pliers.
ADJUSTMENT:
Loosen the yoke bolt just enough to slide or rotate the yoke to the desired position. Tighten the yoke
bolt securely with a 7/16" box end wrench. If necessary loosen the wing screws and tilt the Hot Spot
to the desired position. Re-tighten the wing screws firmly by hand. After a few minutes check the
assembly for any slippage and re-tighten. Connect the speaker wires and the installation is
complete.
