Canon CR-135I User Manual
Page 16
16
3
Place the ink cartridge shown in the diagram below.
CAUTION
Do not touch the electrical contact on the carriage. Doing so
may cause a malfunction.
NOTE
Do not use more than one cartridge by rotation. If you do so,
applications cannot check the ink level precisely.
4
Push down the ink cartridge until it clicks into place.
IMPORTANT
Make sure that the ink cartridge is securely in place.
5
Squeeze the Print Position Adjustment Lever and move it
to adjust the print position.
Top:
1.92" (48.8 mm) from the bottom edge of the document
Bottom:
1.17" (29.6 mm) from the bottom edge of the document
6
Carefully replace the Top Cover.
