EFORE

When Using a GY501 Gyro Gain Adjustment Function

[Transmitter Settings]

Adjust both the ATV rates to 90% at the transmitter Ch5 ATV function.

[GY501 Settings]

Operation Mode Setting function:
Select the gyro operation mode at the GY501 Mode screen. (AVC, NOR, or
CMT)
Gyro Gain Adjustment function:
Set the G:1 and G:2 gains at the GY501 G:x screen.

- Relationship between transmitter and gyro setting

Transmitter

settings

GY501mode

settings

Actual gain

ATV rates

NOR

AVC

CMT

CH5 Switch CH5 Switch

Forward side Front side
90% (Fixed) 90% (Fixed)

Normal mode Normal mode

AVCS mode AVCS mode

Normal mode AVCS mode

(G2) (G1)

100% - 0% - 100%
