Page 13: Relationship between transmitter and gyro setting

EFORE

When Using a T9Z World Champion Model Transmitter
Gyro Sense Mixing

The Gyro Sense Mixing (GYR) function lets operator perform two-point gain
adjustment at each condition. Set the sensitivity at all conditions.

[GY501 Settings]

Select the gyro operation mode at the GY501 Mode screen. (AVC, NOR, or
CMT)

[Transmitter Settings]

ATV function:
Adjust both the RATE A and RATE B rates to 100% at the transmitter ATV
function setup screen.
Gyro Sense Mixing function:
1. Select the Dual Mode (DUO) at the transmitter Gyro Sense Mixing setup
screen.
2. Set the GAIN1 and GAIN2 gains.
(The following page shows a setting example in the CMT mode.)

[Sensitivity Display]

The gain display indicates the actual gain at the GY501 G:1 and G:2 screen.
The following shows the relationship between transmitter and gyro setting
when GY501 sensitivity setting is 100% in both the G1 and G2 gain modes.

- Relationship between transmitter and gyro setting

Transmitter

settings

GY501mode

settings

Actual gain

GAIN1
GAIN2

NOR

AVC

CMT

0% - 50% - 100%

Normal mode

AVCS mode

Normal mode AVCS mode

(G2) (G1)

100% - 0% - 100%
