Futaba 9CPS - Manual (Page 46)

Using FLAP-TRIM (camber) to adjust flaperons: (ACRO/GLID )
FLAP-TRIM assigns the primary flaperon control [defaults to VR(A)] to allow trimming in
flight of the flap action of flaperons. (Note: even if FLAP-TRIM is made active with AIL-DIFF,
it will not have any effect. The ONLY function that allows control of the ailerons as flaps
in the AIL-DIFFconfiguration is AIRBRAKE.) Most modelers use AIRBRAKE, or programmable
mixes, to move the flaps to a specified position via movement of a switch.
FLAP-TRIM may also be used as the primary flap control in flight. By doing so, you can assign CH6 to a 3-position
switch, with a "spoileron", neutral, and "flaperon" position, and even adjust the percentage traveled as flaperon/spoileron
by changing the Flap Trim travel. (Note that there is only one setting, not independent settings for up and down travel.)
46
Add FLAP-TRIM to allow the model=s
ailerons to be trimmed together as
flaps at any time during the flight,
with a maximum travel of 5% of the
total flap travel set in F
LAPERON.
Where next?
Open the F LAP-TRIM function.
Adjust the travel available to the
flaperons when turning the CH6 D
IAL .
(Ex: 5%).
Optional: Use as total flap control.
Reassign CH6ís primary control in
AUX-CH to your desired flap control.
(Ex: right slider)
Close menu.
for 1 second.
(If basic, again.)
to FLAP-TRIM.
to 5%.
to 50%.
to AUX-CH.
to CH6. to Vr-E.
Adjust individual servo's SUB-TRIMs: see p. 42 and END POINTs: see p. 32.
Set up A
IRBRAKE mix: see p. 56 and ELEV-FLAP mix: see p. 55.
Mix flaperon's flap movement to an additional inboard flap (plugged into aux1):
see p. 54.
View additional model setups on the internet:
www.futaba-rc.com\faq\faq-9c.html.
The function is automatically activated with FLAPERON; however, the default travel is 0.
