Fig. 11 – Futaba 8JN User Manual

Page 13

background image

No.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

Details

Upper case

Middle case

Bottom case

Pinion motor

1 st gear

2nd gear

3rd gear

Final gear

2nd shaft

Intermediate
shaft

Output shaft

Spacer washer

Seal ring

Radial ball
bearing

Pan head screw

Truss screw

Motor

Slider

Volume

Grommet

Name plate

Fiber washer

Servo horn

Toothed washer

Phillips pan
head screw

E ring

0 ring

Quantity

1

1

1

1

1

1

1

1

1

1

1

1

1

2

4

2

1

1

1

1

1

2

1

1

1

Remarks

M2x24

M 2 x 5

16

M2

M2x5

Fig. 11
