Before Using
Transmitter T3PM
Nomenclature
Throttle trim (DT2)
Edit keys
LCD screen
Pilot lamp
CH3 switch ( SW2)
(See page 16 for the operating
instructions.)
Steering dual rate
lever (DT3)
(See page 16 for the operating instructions.)
ATL lever (DT4)
(See page 16 for the operating instructions.)
Antenna
Power switch
Steering trim (DT1)
(See page 16 for the operating instructions.)
Mechanical ATL
adjusting screw
(See page 17 for the
adjustment instructions.)
Steering wheel
Throttle
trigger
Grip Handle
Push switch (SW1)
Crystal
Cover
*The switches and levers in the figure are
shown in the initial setting position.
Precautions when turning the power
switch on and off.
When the data was changed using the edit
keys or trim levers, wait at least two seconds
before turning off the power. If the power is
turned off within two seconds after the data
was changed, the new data will not be written
to memory.
