11
Repairs can be made to the Micro P-38 Lightning by using the following items:
● Thick Foam Safe CA (for parts adhesion), GPMR6072
● Foam safe CA accelerator, GPMR6035
● Two sets of needle nose pliers or hemostats, HCAR0625
● Hobby Knife (#11 blade), RMXR6900
● Clear tape
REPAIRS
Stock No. Description
FLZA6500 Wing
FLZA6501 Pod/Boom
Set
FLZA6502 Tail Surfaces Set
FLZA6503 Spinners
(2)
FLZA6504 Landing Gear Set
FLZA6505 Canopy
FLZA6506 Pilot
FLZA6507 Battery
Hatch
FLZA6508 Hardware Set
Stock No. Description
FLZA6509 Decals
FLZA6510 Gearbox
FLZA6511 Motor Set w/Pinions
FLZA6512 Propeller (2 pcs.)
FLZA6513 Aileron Servo Set
GPMP0770 1S 3.7V 250mAh 20C LiPo
TACJ2402 TTX402 2.4GHz Transmitter
TACL1424 Micro Receiver w/Servos
To order replacement parts for the Micro P-38 Lightning, use the order numbers in the list below. Replacement parts
are available only as listed. Replacement parts are not available from Product Support, but can be purchased from
hobby shops or mail order/Internet order firms. If you need assistance locating a dealer to purchase parts from, contact:
Product Support
Phone: 217-398-0007
Fax: 217-398-7721
E-mail: [email protected]
REPLACEMENT PARTS
To replace the propellers, fi rst make sure the battery is
unplugged. Remove the spinner by gently wiggling it and
breaking the glue joint that holds the spinner in place on
the propeller. Gently and carefully hold the motor shaft with
needle nose pliers or a hemostat to keep it from rotating and
gently unscrew the propellers from the shafts. As shown in
the picture, the left propeller unscrews clockwise and the
right propeller unscrews counterclockwise. BE SURE you
replace the propeller with the same rotating direction
propeller! The spinner can be glued back on the propeller
with a small amount of aliphatic (white) glue. Allow the glue
to dry suffi ciently before fl ying the model. Gently pull on
the spinner to make sure it is really glued to the propeller.
PROPELLER REPLACEMENT
