3
ADDITIONAL ITEMS REQUIRED
Radio Control System
The Fw-190 Rx-R (receiver ready) comes with the servos
installed, so all that is required is a 6-channel transmitter
and receiver. The Tactic
™ TTX600 2.4GHz spread spectrum
6-channel radio control system (TACJ2600) is included with
the RTF (ready to fl y) version of the Fw-190, so this same
radio system is ideal for your Rx-R version, too.
❍ Tactic TTX600 2.4GHz 6-channel system (TACJ2600)
❍ (4) AA batteries will be required to operate the
recommended transmitter (FUGP7308).
Battery and Charger
The Fw-190 RTF comes complete with a motor battery and
charger. The Fw-190 Rx-R version requires an 1800mAh 11.1V
LiPo battery and LiPo Charger. The Fw-190 was designed for
the Flyzone 1800mAh 11.1V LiPo battery. Other LiPo batteries
similar in size with the same voltage and capacity may also
work, but they may not fi t properly in the battery compartment
or have the same type of battery connector. In addition to a
battery, a LiPo battery charger is also required and there
are several that will work (depending on your budget and
requirements). A safe, economical charger is the ElectriFly
®
3S (3-cell/ 11.1V) LiPo Smart Charger (GPMM3318). The
Smart Charger includes adapters to charge from a 110V wall
outlet or a 12V DC outlet from a car. The Smart Charger will
take approximately 2-1/2 to 3 hours to fully charge the battery.
Some pilots prefer to have several batteries and charge them
faster so they can fl y more. For charging up to four batteries
faster at the same time, the Great Planes PolyCharge4
™ DC-
powered LiPo charger (GPMM3015) is recommended. But
unlike the Smart Charger, the PolyCharge4 does not have
an internal LiPo cell balancer which is a critical component in
making sure your LiPo batteries charge effi ciently and evenly.
So, for each LiPo battery you wish to charge simultaneously,
one Great Planes Equinox ™ LiPo Cell Balancer (GPMM3160)
will also be required. Finally, the PolyCharge4 does not have
AC capability, so if wall charging is a priority, a separate AC
12-Volt power source must also be purchased separately. A
suitable power supply for the PolyCharge4 is the Great Planes
12V 12A DC power supply (GPMP0901)
Required Assembly Tool
Other than common hobby tools this is the list of adhesives
and building supplies that are required to fi nish the Fw-190.
❍ Small needle-nose pliers (HCAR0625) or hemostats
(BRUR1302)
❍ #1 Phillips screwdriver (DTXR0174)
❍ Thread-locking cement (GPMR6060)
❍ Small crescent wrench
❍ Great Planes stick-on lead weight (Optional, GPMQ4485)
ORDERING REPLACEMENT PARTS
Replacement parts for the Hobbico Flyzone Fw-190 are
available using the order numbers in the
Replacement Parts
List that follows. The fastest, most economical service can
be provided by your hobby dealer or mail-order company.
To locate a hobby dealer, visit the Hobbico web site at www.
hobbico.com . Choose “Where to Buy” at the bottom of the menu
on the left side of the page. Follow the instructions provided on
the page to locate a U.S., Canadian or International dealer.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or fax at (217) 398-7721, but full
retail prices and shipping and handling charges will apply.
Illinois and Nevada residents will also be charged sales tax.
If ordering via fax, include a Visa
® or MasterCard ® number
and expiration date for payment.
Mail parts orders Hobby Services
and payments by 3002 N Apollo Drive, Suite 1
personal check to: Champaign IL 61822
Be certain to specify the order number exactly as listed in the
Replacement Parts List . Payment by credit card or personal
check only; no C.O.D.
If additional assistance is required for any reason, contact
Product Support by telephone at (217) 398-8970, or by e-mail
at
[email protected] .
Order No. Description
REPLACEMENT PARTS LIST
HCAA6425
HCAA6426
HCAA6427
HCAA6428
HCAA6429
HCAA6430
HCAA6431
HCAA6432
HCAA6433
HCAA6434
HCAA6435 Fuselage Set Fw-190 RTF/Rx-R
Wing Set Fw-190 RTF/Rx-R
Stabilizer Fw-190 RTF/Rx-R
Retract Part Set Fw190 RTF/Rx-R
30 Amp Esc Fw-190 RTF/Rx-R
1800mah 20c Lipo Fw-190 RTF
Hatch Fw-190 RTF/Rx-R
Motor Fw-190 RTF/Rx-R
Wheels Fw-190 RTF/Rx-R
10x6 3-bld Prop Fw190 RTF/Rx-R
Spinner Fw-190 RTF/Rx-R
KIT INSPECTION
Before starting to build, inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not
of acceptable quality, or if you need assistance with assembly,
contact
Product Support . When reporting defective or missing
parts, use the part names exactly as they are written in the
Kit Contents list.
Hobbico Product Support
3002 N. Apollo Drive, Suite 1 Ph: (217) 398-8970, ext. 5
Champaign, IL 61822 Fax: (217) 398-7721
E-mail: [email protected]
